Backbone Wireless Bridge
+ KDV
Backbone Wireless Bridge
New
BDCOM Backbone Wireless Bridge
- WiFi6 standard, 5GHz band
- 2402Mbps speed, 3 Gigabit Ethernet ports (including 1 *GSFP)
- Built-in dual-polarized antenna, distance over 15km
- Aluminum alloy housing, IP67 protection
WBR65G-150| Transmission | |
| Frequency | 5.150~5.850GHz |
| Antenna Gain | 5180~5850 MHz |
| Network | |
| Network Interface | Static IP, DHCP client, 802.1Q VLAN, IPv4 & IPv6, DHCPd, SNMP, NTP client |
| Image | |
| Reset Button | Press 10 seconds for Factory reseting |
| Wi-Fi | |
| Wi-Fi | Multi SSID (Max: 4) and Hidden SSID / Transmit Power Setting / Scheduled WiFi On/Off |
| Wifi Protocols | 802.11 a/n/ac/ax |
| General Features | |
| Chipset | IPQ5018+QCN6102+QCA8337 |
| Display | SYS, WAN, LAN, WIFI, Signal*8 |
| Power | PoE 48V or DC 12~24V |
| Power Consumption | ≤18W |
| Protection Standard | IP65 |
| Operating Temperature | -30~55°C |
| Dimension | 218×243×64mm |
| Weight | 1.6Kg |
| ESD | Air: ±15KV Touch: ±8KV |
| Antenna Type | Integrated 20dBi Dish antenna, Vertical/horizontal dual polarization |
| Button | Set Master / Slave mode |
| Flash | SPI NOR 16MB + NAND 128MB |
| QoS | TDMA technology (4 queue priority) |
| Speed | 2402Mbps |
| Management Type | SSH, Telnet, Http/Https, SNMP read, Route tracking, Ping watchdog |
| Working mode | AP mode / Relay mode |
